The design of Gamia Metal was made holding in consideration the installation problems;
the results is a spiral stair of different diameters, with railings always according to code
and with rise adjustement’s system which assures a climb of every height in any project.
Thanks to the above system and to pratical instructions for the assembly, the installation is a snap.
The distinctive feature of Gamia Metal is surely the design of railings. Vertical spindles
connected with the flexuous handrail assure an absolute structural rigidity.
Diameters = Ø 120 cm - 140 cm - 160 cm.

Steps - Manufactured from stamped plate, with rubber matting; step angle 30°, round or triangular landing angle 60°, square landing angle 90° for round or square opening
Riser heights - standard min. 210 mm. (8 1/4”) - max 230 mm. (9”) (for risers 200 - 210 mm.
(7 7/8” - 8 1/4”); 230 ÷ 240 mm. (9” - 9 1/2”); it is possible to cut the balusters during the assembly. Note UK Building Regs has a Maximum Rise Height of 220mm.
Please Note the 1200mm diameter Option will not comply with Building Regulations
Railing - with metal steel tubing balusters ø 22 mm. (7/8”)(clear space among the balusters< 100 mm., 4”); flexible plastic handrail (handrail height = 1000 mm, 39 3/8”)
Finishes and colours - metal: durable powder coat (steps - grey ; balusters
- grey); plastic components, rubber matting and screws: black

The design of Gamia Metal was made holding in consideration the installation problems;
the results is a spiral stair of different diameters, with railings always according to code
and with rise adjustement’s system which assures a climb of every height in any project.
Thanks to the above system and to pratical instructions for the assembly, the installation is a snap.
The distinctive feature of Gamia Metal is surely the design of railings. Vertical spindles
connected with the flexuous handrail assure an absolute structural rigidity.
Diameters = Ø 120 cm - 140 cm - 160 cm.

Steps - Manufactured from stamped plate, with rubber matting; step angle 30°, round or triangular landing angle 60°, square landing angle 90° for round or square opening
Riser heights - standard min. 210 mm. (8 1/4”) - max 230 mm. (9”) (for risers 200 - 210 mm.
(7 7/8” - 8 1/4”); 230 - 240 mm. (9” ÷ 9 1/2”); it is possible to cut the balusters during the assembly. Note UK Building Regs has a Maximum Rise Height of 220mm.
Please Note the 1200mm diameter Option will not comply with Building Regulations
Railing - with metal steel tubing balusters ø 22 mm. (7/8”)(clear space among the balusters< 100 mm., 4”); flexible plastic handrail (handrail height = 1000 mm, 39 3/8”)
Finishes and colours - metal: durable powder coat (steps - light grey Ral 7035; balusters
- embossed black); plastic components, rubber matting and screws: black

The design of Gamia Wood was made holding in consideration the installation problems;
the results is a spiral stair of different diameters, with railings always according to code
and with rise adjustement’s system which assures a climb of every height in any project.
Thanks to the above system and to pratical instructions for the assembly, the installation is a snap.
The distinctive feature of Gamia Wood is surely the design of railings. Vertical spindles
connected with the flexuous handrail assure an absolute structural rigidity.
The use of wood treads allows this model to blend well in any room, giving warmth and
simple elegance.
Diameters = Ø 120 cm - 140 cm - 160 cm.
Steps -Manufactured from solid beech wood, thickness 38 mm (11/2”); step angle 30°,
round or triangular landing angle 60°, square landing angle 90° for round or square opening
Riser heights - standard min. 210 mm. (8 1/4”) - max 230 mm. (9”) (for risers 200 - 210 mm.
(7 7/8” - 8 1/4”); 230 - 240 mm. (9” - 9 1/2”); it is possible to cut the balusters during the assembly. Note UK Building Regs has a Maximum Rise Height of 220mm.
Please Note the 1200mm diameter Option will not comply with Building Regulations
Railing - with metal steel tubing balusters ø 22 mm. (7/8”)(clear space among the balusters < 100 mm., 4”); flexible plastic handrail (handrail height = 1000 mm, 39 3/8”)
finishes and colours = wood: polished with water varnish (Natural 12); metal: durable
powder coat (embossed black); plastic components, rubber matting and screws: black

The exterior staircase…with that extra touch!! Finished with special treatments that
avoid any defects caused by the normal galvanising applications!
All nuts and bolts are in stainless steel. Practical, thanks to the modular no post system, it
may be rapidly and easily installed thanks to the fact that the stair risers may be
adjusted. The handrail is in moplen with an ergonomic design which grants an easy grip.
The basic model includes 12 steps + 1 universal landing + railing with handrail... but you
can personalise your staircase thanks to the accessories!
Extra step kit
For the spiral staircases Exterior the minimum ideal opening should be 5 cm larger than the diameter of the staircase.
Diameters = Ø 120 cm - 140 cm - 160 cm
Please Note the 1200mm diameter Option will not comply with Building Regulations
basic model = 13 steps
total height min/max = 273/299 cm Risers adjust from 210 to 230mm (220 is UK Max rise height)
colour of the steel = anthracite grey
colour of the handrail = black
Protective treatment against any type of weather conditions!
